Throttle Cable 86528050 6000021 for New Holland L565 L865 LX565 LX665 LX865
$59.99
In Stock
$59.99
Sale price
$59.99
Regular price
This aftermarket hand-throttle cable replaces New Holland 86528050, 6000021, and 86501120 on compatible L565, L865, LX565, LX665, LX865, LX885, and LX985 skid steer loaders.
Estimated delivery between
Let Northline Parts Do the Heavy Lifting for You!
Not sure which part you need? Our team can help you find the right replacement.
Parts Support Hours: Monday–Friday, 8:00 AM–5:00 PM CT
Live Chat: Available 24/7
I reached out for some replacement head bolts and they responded quickly with a few questions and cautionary information and is sending me some bolts. Great customer service! Thanks
Edward H. — Verified customer
Compatible Models
We do our best to list all compatible models. Although this may be the part you need, your exact model may not appear below.
Compatible equipment / model
- New Holland L565 skid steer
- New Holland L865 skid steer
- New Holland LX565 skid steer
- New Holland LX665 skid steer
- New Holland LX865 skid steer
- New Holland LX885 skid steer
- New Holland LX985 skid steer
- New Holland 234 tractor only when 86528050 is confirmed
Product Overview
A skid steer that will not reach governed speed, will not hold a throttle setting, or has a lever that feels stiff may have a stretched, corroded, frayed, or broken cable. Replacing the mechanical link restores direct control when the engine lever itself moves freely.
New Holland cable length and bracket location can change by model and serial number. Compare the overall sheath length, threaded ends, clevis or eye fittings, adjustment range, and routing to the removed cable.
Key Features & Performance
- Restores hand-throttle movement on matching New Holland loaders
- Replaces several common cable reference numbers
- Covers L and LX skid steer families beyond the shorter source title list
- Useful for stiffness, lost travel, fraying, and broken inner wire
- Aftermarket machine-control cable
Replaces Part Numbers
- 86528050
- 6000021
- 60-00021
- 86501120
- 157098031
Common Uses
- Fixing a throttle lever that is hard to move
- Restoring full engine-speed range after cable stretch
- Replacing a cable with a damaged sheath or broken end
- Returning a loader to predictable engine control
Technical Specifications
- Product Type: Throttle control cable
- Equipment: New Holland skid steer loader
- Control: Hand throttle to engine speed lever
- Primary Models: L565, L865, LX565, LX665, LX865, LX885, LX985
- Replacement Type: Aftermarket
Installation & Fitment
- Record the loader model and serial number and match the original cable reference
- Compare overall length, sheath length, end fittings, adjusters, and brackets
- Photograph routing before removal and keep the cable away from lift linkages, heat, and sharp edges
- Set adjustment so idle and full governed speed are reached without forcing either stop
- Cycle the loader controls and throttle through full movement before operating
Compatibility Notice
Northline Parts does its best to list all known compatible models, but the correct part may fit an application not shown.
Model names and year ranges are a starting point. Match the original reference number, configuration, connections, mounting points, and product-specific details before ordering.
Frequently Asked Questions
Q: Can this fix an engine that will not make full RPM? A: Yes if the cable is not moving the engine lever fully, but governor and engine faults must also be checked.
Q: Why does serial number matter? A: Bracket and cable-length changes can occur within the same loader model.
Q: Does it fit LX885 and LX985 even though the short title stops at LX865? A: Fitment references include LX885 and LX985 when 86528050 and the cable dimensions match.
Part Summary
keywords: New Holland 86528050 throttle cable, 6000021 skid steer cable, LX565 hand throttle repair, LX865 engine control cable, LX885 throttle cable replacement, L565 stiff throttle lever, 86501120 replacement cable, aftermarket New Holland skid steer cable
Brand names, model numbers, and reference part numbers are used for identification and compatibility purposes only. Verify the original component, dimensions, and application before purchase.
