Toyota Vacuum Switching Valve 192000-3042 for 4Runner Tacoma T100 MR2
$26.99
In Stock
$26.99
Sale price
$26.99
Regular price
This vacuum switching valve replaces Denso 192000-3042 and related Toyota references on compatible 4Runner, Tacoma, T100, MR2, and Paseo vacuum-control systems.
Estimated delivery between
Let Northline Parts Do the Heavy Lifting for You!
Not sure which part you need? Our team can help you find the right replacement.
Parts Support Hours: Monday–Friday, 8:00 AM–5:00 PM CT
Live Chat: Available 24/7
I reached out for some replacement head bolts and they responded quickly with a few questions and cautionary information and is sending me some bolts. Great customer service! Thanks
Edward H. — Verified customer
Compatible Models
We do our best to list all compatible models. Although this may be the part you need, your exact model may not appear below.
Compatible equipment / model
- 1991-1997 Toyota 4Runner when 192000-3042 is specified
- 1995-1997 Toyota Tacoma with matching VSV
- Toyota T100 with matching 192000-3042 vacuum circuit
- Toyota MR2 with matching valve and hose routing
- Toyota Paseo with matching valve and hose routing
- Other Toyota applications only when the Denso number, ports, and control function match
Product Overview
An emissions code, rough operation during a commanded vacuum change, or an actuator that never moves can be caused by the VSV—but split hoses, blocked ports, a failed vacuum actuator, or missing ECU command are common. Test the valve for click, resistance, flow, and leakage first.
The solenoid routes engine vacuum to a specific emissions or engine-control device. Similar Toyota VSVs use different normally-open/closed flow paths and hose layouts, so the Denso number, port markings, bracket, connector, and circuit function must match.
Key Features & Performance
- Electrically controlled vacuum routing
- Crosses to Denso 192000-3042
- For selected early Toyota truck and car applications
- Addresses verified electrical or internal-leakage failure
- New aftermarket solenoid
Replaces Part Numbers
- 192000-3042
- 192000-3130
- 17600-16010
Common Uses
- Repairing a vacuum actuator that does not receive command vacuum
- Replacing a valve with open windings or internal leakage
- Correcting a circuit-specific emissions fault after hose testing
Technical Specifications
- Product Type: Vacuum Switching Valve Solenoid
- Primary Application: Toyota vacuum-control systems using Denso 192000-3042
- Package Quantity: 1 valve
- Condition: New
- Replacement Type: Aftermarket
- Primary Reference: 192000-3042
- Related References: 192000-3130; 17600-16010
- System: Engine / emissions vacuum control
- Operation: ECU-switched solenoid valve
- Condition: New aftermarket
Installation & Fitment
- Label every vacuum hose and connector
- Inspect hoses for cracks, wrong routing, and blockage
- Compare port markings and normally-open/closed behavior
- Mount in the original orientation, clear codes, and command the valve with a scan tool when supported
Compatibility Notice
Northline Parts does its best to list all known compatible models, but the correct part may fit an application not shown.
Model, production date, serial number, connector, dimensions, installed options, and previous repairs can affect fitment. Compare the original component and reference information before purchase.
Frequently Asked Questions
Q: Can the valve click and still be bad? A: Yes. The coil may move while the internal valve leaks or remains restricted; test airflow and vacuum holding.
Q: Does this fit every 1991-1997 Tacoma? A: Tacoma began in 1995 and used multiple VSVs. Match the exact circuit and valve number.
Q: How do I confirm this is the correct part? A: Match the complete Denso/Toyota number, connector, resistance, number and size of ports, flow logic, bracket, hose diagram, vehicle engine, and emissions label.
Q: Is this supplied by the original equipment manufacturer? A: No. This is a new aftermarket item. Brand, model, and part numbers are used only to identify compatible applications.
