Hot Cams Stage 2 Camshaft 1043-2 for Honda TRX400EX TRX400X XR400R
$49.99
In Stock
$49.99
Sale price
$49.99
Regular price
Hot Cams Stage 2 camshaft 1043-2 for compatible Honda TRX400EX, TRX400X, and XR400R engines prepared for a performance camshaft.
Estimated delivery between
Let Northline Parts Do the Heavy Lifting for You!
Not sure which part you need? Our team can help you find the right replacement.
Parts Support Hours: Monday–Friday, 8:00 AM–5:00 PM CT
Live Chat: Available 24/7
I reached out for some replacement head bolts and they responded quickly with a few questions and cautionary information and is sending me some bolts. Great customer service! Thanks
Edward H. — Verified customer
Compatible Models
We do our best to list all compatible models. Although this may be the part you need, your exact model may not appear below.
Compatible equipment / model
- 1999–2008 Honda TRX400EX
- 2009 Honda TRX400X
- 2012–2014 Honda TRX400X
- 1996–2004 Honda XR400R with the matching valvetrain
Product Overview
This cam is for an owner deliberately moving power higher in the rev range—not for fixing low compression, poor jetting, tight valves, a stretched chain, or a worn head. The engine must be healthy and the fuel, exhaust, valve-train, and riding setup should support the more aggressive profile.
The 1043-2 cam changes valve lift and duration to favor stronger mid-to-top performance. Piston-to-valve clearance, spring condition, rocker or follower surfaces, decompression arrangement, chain and tensioner condition, timing marks, and valve lash must be verified on the actual build.
Key Features & Performance
- Stage 2 performance profile for matching Honda 400 engines
- Hot Cams part number 1043-2
- Designed to strengthen midrange and upper-rpm breathing
- Published lift and duration data support informed engine setup
Replaces Part Numbers
- 1043-2
Common Uses
- Building a stronger mid-to-top-end trail or sport engine
- Replacing a worn cam as part of a correctly matched performance build
- Coordinating cam timing with intake, exhaust, and fuel calibration
- Refreshing the valvetrain after clearance and oiling inspection
Technical Specifications
- Product Type: Stage 2 Performance Camshaft
- Part Number: 1043-2
- Intake Lift: 9.0 mm
- Intake Duration: 254 degrees at 1 mm
- Exhaust Lift: 8.9 mm
- Exhaust Duration: 248.5 degrees at 1 mm
- Condition: New
Installation & Fitment
- Inspect rockers, journals, chain, sprocket, guides, tensioner, springs, and oil delivery
- Measure piston-to-valve and coil-bind clearance for the complete engine combination
- Set cam timing and cold valve lash to the cam maker’s specification
- Pre-lubricate, rotate by hand through multiple cycles, and follow the specified break-in
Compatibility Notice
Northline Parts does its best to list all known compatible models, but the correct part may fit an application not shown.
Model, production date, serial number, electrical or fuel-system version, dimensions, installed options, and previous repairs can affect fitment. Compare the original part and application information before purchase.
Frequently Asked Questions
Q: Will a Stage 2 cam fix an engine with low compression? A: No. Ring, cylinder, valve, and head problems must be repaired before performance tuning.
Q: Does this cam require fuel or exhaust tuning? A: The best setup depends on the engine and supporting parts; jetting or EFI and exhaust changes may be needed to use the new airflow safely.
Q: How do I confirm fitment before ordering? A: Match the original reference number where available, then compare the removed part, dimensions, connections, mounting details, model, serial or production information, and package photos.
Q: Is this an original-equipment part? A: No. This is a new aftermarket part. Brand names and reference numbers are used only to identify compatible applications.
Part Summary
keywords: Hot Cams 1043-2, Honda TRX400EX Stage 2 cam, TRX400X camshaft upgrade, XR400R performance cam, Honda 400 midrange power, 1043-2 valve lift
Brand names, model numbers, and reference part numbers are used for identification and compatibility purposes only. Verify the original component, dimensions, and application before purchase.
