Honda Big Red MUV700 Regulator Rectifier BT010008 for 2009–2013
$36.99
In Stock
$36.99
Sale price
$36.99
Regular price
Regulator-rectifier cross-referencing BT010008 for compatible 2009–2013 Honda Big Red MUV700 side-by-side models.
Estimated delivery between
Let Northline Parts Do the Heavy Lifting for You!
Not sure which part you need? Our team can help you find the right replacement.
Parts Support Hours: Monday–Friday, 8:00 AM–5:00 PM CT
Live Chat: Available 24/7
I reached out for some replacement head bolts and they responded quickly with a few questions and cautionary information and is sending me some bolts. Great customer service! Thanks
Edward H. — Verified customer
Compatible Models
We do our best to list all compatible models. Although this may be the part you need, your exact model may not appear below.
Compatible equipment / model
- 2009 Honda Big Red MUV700
- 2010 Honda Big Red MUV700
- 2011 Honda Big Red MUV700
- 2012 Honda Big Red MUV700
- 2013 Honda Big Red MUV700
Product Overview
A battery that repeatedly goes flat, charging voltage that climbs too high, flickering lights, or blown bulbs can point to a regulator-rectifier. The stator, battery, connectors, grounds, accessory load, and wiring must be tested because a weak battery or burnt plug can damage the new unit or create the same readings.
The regulator-rectifier converts stator AC output to DC and limits system voltage. Match the plug, pin arrangement, wire colors, case and heat-sink shape, mounting holes, and BT010008 reference before connecting it; the wrong pinout can damage the electrical system.
Key Features & Performance
- Controls charging voltage on matching Big Red MUV700 systems
- Converts stator output for battery and accessory use
- Cross-references BT010008
- Addresses confirmed overcharging, undercharging, or rectifier-diode failure
Replaces Part Numbers
- BT010008
Common Uses
- Replacing a regulator that allows excessive charging voltage
- Repairing low DC output after the stator and wiring pass tests
- Correcting diode leakage that drains or destabilizes the system
- Restoring charging after a heat-damaged regulator connector is repaired
Technical Specifications
- Product Type: Regulator Rectifier
- Electrical System: 12 V charging system
- Vehicle: Honda Big Red MUV700
- Model Years: 2009–2013
- Condition: New aftermarket
Installation & Fitment
- Load-test the battery and measure stator AC output before replacement
- Repair loose, melted, or corroded terminals and confirm clean engine and frame grounds
- Compare plug shape, pinout, case, heat sink, and mounting pattern
- Mount for proper heat transfer and recheck charging voltage at idle and raised rpm
Compatibility Notice
Northline Parts does its best to list all known compatible models, but the correct part may fit an application not shown.
Model, production date, serial number, electrical or fuel-system version, dimensions, installed options, and previous repairs can affect fitment. Compare the original part and application information before purchase.
Frequently Asked Questions
Q: Can a failed regulator overcharge the battery? A: Yes. Loss of voltage control can boil a battery, brighten or burn bulbs, and damage electronics.
Q: Why test the stator before installing this part? A: A shorted or weak stator can create low output that a new regulator cannot correct.
Q: How do I confirm fitment before ordering? A: Match the original reference number where available, then compare the removed part, dimensions, connections, mounting details, model, serial or production information, and package photos.
Q: Is this an original-equipment part? A: No. This is a new aftermarket part. Brand names and reference numbers are used only to identify compatible applications.
Part Summary
keywords: Honda Big Red regulator rectifier, MUV700 charging repair, BT010008 replacement, Honda battery overcharging, 2009 2013 Big Red regulator, UTV low voltage fix
Brand names, model numbers, and reference part numbers are used for identification and compatibility purposes only. Verify the original component, dimensions, and application before purchase.
